D-SUB Connector,IDC Type,9 15 25 37 pins Male Female PX-222 & PX-222N

D-SUB Connector IDC Type 9 15 25 37 pins Male Female
Order Information
PX1-222-XX-M-L
Type: 222 , 222N

XX-No.of 09,15,25,37pins
M-Male F-Female
L-Blue B-Black

Material:

Housing: PBT+30% Glass filled ,UL94V-0

Contacts: Brass ,Gold Plating

Shell: Steel, Nickel Plating

Electrical Characteristics:

Current Rating: 1 AMP

Insulator Resistance: 1000MΩ Min. at DC 500V

Withstanding Voltage: 500V AC (rms) for 1 minute

Contact Resistance: 20mΩ Max. Initial

Operating Temperature: -55°C~+105°C

Product Detail

Part No.	Description
PX1-222-09-F-L	D-SUB Connector With IDC Type,09 Pin,Female,Blue.
PX1-222-09-M-L	D-SUB Connector With IDC Type,09 Pin,Male,Blue.
PX1-222-15-F-L	D-SUB Connector With IDC Type,15 Pin,Female,Blue.
PX1-222-15-M-L	D-SUB Connector With IDC Type,15 Pin,Male,Blue.
PX1-222-25-F-L	D-SUB Connector With IDC Type,25 Pin,Female,Blue.
PX1-222-25-M-L	D-SUB Connector With IDC Type,25 Pin,Male,Blue.
PX1-222-37-F-L	D-SUB Connector With IDC Type,37 Pin,Female,Blue.
PX1-222-37-M-L	D-SUB Connector With IDC Type,37 Pin,Male,Blue.
