UL STYLE: UL2678
Rate temperature : -40°C ~ 125°C
Rate voltage : 150V
Flame test : VW-1 & CSA FT1,FT2
Conductor: 30AWG Tinned Copper
Insulation : TPE 125°,Halogen Free; Color: Gray
ELECTRONIC CHARACTERISTICS:
Spark test : 1500V
Dielectric strength test : 1.5KV in 15 sec. Min.
Conductor resistance : 377Ω/km Max.
Insulation resistance : 0.75MΩ/km Min.
